Discovery 24 Series

This system features 24 channels of EEG Biofeedback recording including: 22 channels connected to a standard electrode cap, plus 2 channels of differential inputs with separate references, useful for monitoring any of a wide range of EEG or related potentials. It offers 1024 samples per second on all channels, with 24-bit resolution, and an amplifier bandwidth from DC (0.000 Hz) to 80 Hz. A lightweight, portable device, it is ideal for use with laptop computers for remote or home training, as well as in clinical or laboratory use.  The unit is entirely powered by the USB interface, eliminating the need for batteries, while maintaining client safety.

Choose a package below to see what is included



The BrainMaster Discovery 24 introduces the next generation of EEG biofeedback in a high-quality, low-cost system answering the advanced needs of the clinical and research communities. It incorporates 24 channels of EEG Biofeedback using technology based upon the continued evolution of the BrainMaster series of biofeedback monitors and trainers. Incorporating low-noise DC-sensitive amplifiers, 24-bit analog-to-digital converters, an optically and magnetically isolated USB interface, and compatibility with a range of software, it is the natural choice for multi-channel EEG. 392-025 392-078 392-079 392-034 392-036 392-037-2

Weight 14 lbs
Dimensions 15 × 12 × 10 in

Weight of Product: 1.5 lbs
Dimensions: 15 × 12 × 10 in
